613.2545.01 TI25
Inserts
Part number 613254501TI25
HORN Inserts 613.2545.01 TI25 for Gewinden
Please note:Technical instructions
Cutting diameter (Ds)
21.7
mm
eclass-shortcut
21-18-20-11
ISO_SSC
HORN313113$84R$$$$$
DIN_SSC
HORN31311384R
Katalog_SSC
313113R
Setting length (E)
3.7
mm
Cutting insert height, Cutting insert thickness (s)
5.75
mm
Pitch (P)
2.5
mm
Maximum pitch (Pmax)
4.5
mm
| Downloads | |
|---|---|
| 613254501_20230112_151937954.STP | Download |
| 613254501.DXF | Download |
| Download all files | |
