DSMR.12.12.88.12.05 TS3K
DS Milling cutter
Part number DSMR1212881205TS3K
HORN DS Milling cutter DSMR.12.12.88.12.05 TS3K for Milling
Please note:Technical instructions
Shank diameter (d2)
12
mm
Cutting diameter (d1)
12
mm
Number of teeth (Z)
12
St.
DIN_CCTMS
ZYL01200105
ISO_CCTMS
ZYL01G1200h$06
Corner radius (r)
0.5
mm
Type (Ausführung)
A
Effective cutting length (l2)
35
mm
Total length (l1)
88
mm
eclass-shortcut
21-18-06-01
| Downloads | |
|---|---|
| DSMR_12_12_88_12_05_20171121_232405894.STP | Download |
| Download all files | |
