DSTM.2.100.010.050 TS3K

DS Milling cutter

Part number DSTM2100010050TS3K

HORN DS Milling cutter DSTM.2.100.010.050 TS3K for Milling

DIN_CCTMS

ZYL00400105

eclass-shortcut

21-18-06-01

Shank tapering angle γ2 (γ2)

20 °

Shank tapering angle γ1 (γ1)

40 °

Total length (l1)

50 mm

Effective cutting length (l2)

2 mm

Corner radius (r)

0.1 mm

Neck diameter (d3)

0.95 mm

ISO_CCTMS

ZYL01F4000h$06

Number of teeth (Z)

2 St.

Cutting diameter (d1)

1 mm

Neck length (l3)

5 mm

Shank diameter (d2)

4 mm
