335.0600.00 TI25
Insert
Part number 335060000TI25
HORN Insert 335.0600.00 TI25 for Milling
Please note:Technical instructions
Corner radius (r)
0.2
mm
Cutting insert thickness, setting length complete (s)
8.7
mm
Maximum milling depth/ depth of groove (tmax)
8
mm
Width of groove (w)
6
mm
plating-seat-size
0
Katalog_SSC
335175R
DIN_SSC
HORN33517584R
ISO_SSC
HORN335175$84R$$$$$
eclass-shortcut
21-18-20-11
Number of teeth (Z)
3
St.
Cutting diameter (Ds)
34.7
mm
| Downloads | |
|---|---|
| 335060000_20210630_114052877.STP | Download |
| 335060000_20210706_165620393.DXF | Download |
| Download all files | |
